HF-30ProAutomatic Cobot Palletizer

Collaborative robot workstation that stacks cartons onto pallets without safety fencing. For medium and low-speed lines: payload up to 30 kg, under 8 cartons per minute.

Max payload: 30kg
Max palletizing height: 2100mm
Palletizing speed: 8 pcs/min, depending on the product
Total power: 3kW

Specifications

ASize range

Arm reach	1900 mm
Max palletizing height	2100 mm
Pallet size	1200 × 1200 × 150 mm

BPerformance

Max payload	30 kg
Palletizing speed	Under 8 pcs/min, depending on the product
Pallet positions	Two (left and right), loaded manually
Recipes	Stores up to 100; can palletize two carton types at once

CElectrical & footprint

Total power	3 kW
Power supply	220 V ±10%, 50 Hz; control voltage DC 24 V
Air supply	0.5–0.7 MPa, 0.23 m³/min (compressor supplied by the customer)
Noise level	Under 60 dB
Machine weight	About 450 kg
Overall dimensions (L × W × H)	About 1505 × 1716 × 3200 mm, including pallet station
Required clear height	3200 mm
Shipping case (L × W × H)	2150 × 1550 × 1760 mm

Footprint · to scale

1505

1716

2.6 m² floor area, mm

Features

How the HF-30Pro is built.

01
No safety fencing needed, which saves floor space.
02
Compact and movable between lines.
03
Graphical programming on the touch screen.

Line position

Where the HF-30Pro sits in a line.

Before

HF-FA500Automatic Carton Sealing Machine

This machine

HF-30ProCarton Erecting, Sealing and Palletizing · 8 pcs/min, depending on the product

After

Ends the sequence: the piece leaves this machine finished for this stage.

FAQ

Questions about the HF-30Pro.

What sizes does the HF-30Pro handle?

For the HF-30Pro, pallet size: 1200 × 1200 × 150 mm.

How fast is the HF-30Pro?

The HF-30Pro runs at Under 8 pcs/min, depending on the product. Speed is counted in single pieces, not sets.

What power and air supply does the HF-30Pro need?

The HF-30Pro needs total power: 3 kW; power supply: 220 V ±10%, 50 Hz; control voltage DC 24 V; air supply: 0.5–0.7 MPa, 0.23 m³/min (compressor supplied by the customer).

How large and heavy is the HF-30Pro?

For the HF-30Pro, machine weight: About 450 kg; overall dimensions (L × W × H): About 1505 × 1716 × 3200 mm, including pallet station; required clear height: 3200 mm; shipping case (L × W × H): 2150 × 1550 × 1760 mm.

Which machines work with the HF-30Pro?

It is fed by the HF-FA500 Automatic Carton Sealing Machine. Which of these you need depends on the box structure and how much of the line is already in place.
