HF-500BAutomatic Paper Tube Labeling Machine
Feeds the printed wrap and pastes it around a paper tube. Adjustable for tube diameters from 28 to 130 mm.
- Paper tube diameter
- φ28–130mm
- Labeling speed
- 40pcs/min
- Label width
- 50–500mm
- Heating power
- 3kW
ASize range
| Paper tube diameter | φ28–130 mm |
| Label width | 50–500 mm |
BPerformance
| Labeling speed | 40 pcs/min |
| Control | Servo motor and PLC |
CElectrical & footprint
| Heating power | 3 kW |
| Power supply | 220 V, single phase |
| Air pressure | 0.6–0.8 MPa |
| Machine weight | 370 kg |
| Machine dimensions | 1070 × 1800 × 1500 mm |
1070
1800
1.9 m² floor area, mm
Line position
Where the HF-500B sits in a line.
Before
Starts the sequence: fed by hand or from a stack.
This machine
FAQ
Questions about the HF-500B.
What sizes does the HF-500B handle?
For the HF-500B, paper tube diameter: φ28–130 mm.
How fast is the HF-500B?
The HF-500B runs at 40 pcs/min. Speed is counted in single pieces, not sets.
What power and air supply does the HF-500B need?
The HF-500B needs heating power: 3 kW; power supply: 220 V, single phase; air pressure: 0.6–0.8 MPa.
How large and heavy is the HF-500B?
For the HF-500B, machine weight: 370 kg; machine dimensions: 1070 × 1800 × 1500 mm.
Which machines work with the HF-500B?
It feeds the HF-440 Semi Automatic Paper Tube 360° Curling Machine. Which of these you need depends on the box structure and how much of the line is already in place.
