HF-UV1210UV Printing Machine for Crafts and Gifts
Flatbed UV printer with a lifting platform that takes work up to 350 mm high on a 1200 × 1000 mm bed. It prints directly on finished objects as well as flat sheets, with white ink and varnish, for craft pieces, gift items and made-up boxes.
- Printing size
- 1200 × 1000mm
- Power
- 500W
- Printing height
- 0–350 mm (can be customised)
- Printing resolution
- 720 × 900, 720 × 1200 or 720 × 1800 dpi
ASize range
| Printing size | 1200 × 1000 mm |
| Printing height | 0–350 mm (can be customised) |
| Platform | Lifting platform |
| Printing resolution | 720 × 900, 720 × 1200 or 720 × 1800 dpi |
| Ink channels | W + CMYK + Lc Lm Lk LLk + V + P; several colour arrangements supported |
| Finishes | White ink, surface UV varnish; frosted and reverse texturing |
| Ink system | Continuous supply by siphon, 550 mL tanks, automatic white ink mixing |
| UV lamp | UV hot light |
| Head position sensing | Magnetic grating |
| File formats | TIFF (RGB and CMYK), BMP, PDF, EPS, JPEG and others |
| Data interface | High-speed USB |
| Computer operating system | Windows 10 |
| Working humidity | 40–70% |
| Working temperature | 20–30 °C |
| Machine construction | Steel structure |
BPerformance
| Control board | Hansen |
CElectrical & footprint
| Power supply | AC 220 V ±10%, 50 Hz |
| Power | 500 W |
FAQ
Questions about the HF-UV1210.
What power and air supply does the HF-UV1210 need?
The HF-UV1210 needs power supply: AC 220 V ±10%, 50 Hz; power: 500 W.
