HF-3250Automatic Paper Box Forming Machine (Double Station)
Two forming stations fed from two material tables, so a lid and its base can be formed at the same time. 34–46 pcs/min on 210–350 g board.
- Max finished box size
- 350 × 250 × 80mm
- Min finished box size
- 120 × 80 × 15mm
- Speed
- 34–46pcs/min
- Machine power
- 5kW
ASize range
| Parameter | Min | Max |
|---|---|---|
| Blank length | 240–540 mm | |
| Blank width | 200–420 mm | |
| Finished box size (L × W × H) | 120 × 80 × 15 mm | 350 × 250 × 80 mm |
BMaterial
| Box styles | 3: long edge not pressing the short edge; long edge pressed over the short edge; wide edge with long side overlapping short side |
| Material | 210–350 g/m² white cardboard, kraft paper and similar; also corrugated board |
| Loading height | 0.5 m on each of the two tables |
| Refill interval | 40–50 minutes |
CPerformance
| Speed | 34–46 pcs/min |
DElectrical & footprint
| Machine power | 5 kW |
| Voltage | 220 V |
| Air supply | 0.6–0.8 MPa |
| Machine dimensions (L × W × H) | 3700 × 1600 × 2000 mm, including conveyor |
3700
1600
5.9 m² floor area, mm
Features
How the HF-3250 is built.
- 01
PLC control with a movable touch screen.
- 02
Two material tables: lids and bases run simultaneously.
- 03
Servo control of the forming station in both directions, adjusted by entering parameters.
- 04
Servo-controlled wall positioning for a neater formed edge.
- 05
Compact footprint.
FAQ
Questions about the HF-3250.
What sizes does the HF-3250 handle?
For the HF-3250, blank length: 240–540 mm; blank width: 200–420 mm; max finished box size (L × W × H): 350 × 250 × 80 mm; min finished box size (L × W × H): 120 × 80 × 15 mm.
How fast is the HF-3250?
The HF-3250 runs at 34–46 pcs/min. Speed is counted in single pieces, not sets.
What materials can the HF-3250 run?
On the HF-3250, material: 210–350 g/m² white cardboard, kraft paper and similar; also corrugated board.
What power and air supply does the HF-3250 need?
The HF-3250 needs machine power: 5 kW; voltage: 220 V; air supply: 0.6–0.8 MPa.
How large and heavy is the HF-3250?
For the HF-3250, machine dimensions (L × W × H): 3700 × 1600 × 2000 mm, including conveyor.
