HF-600BSemi Automatic Magnet Pasting Machine
Places and glues magnets into gift boxes, book-style cases and covers to ±0.5 mm, at 25–35 pieces per minute.
- Max cardboard size
- 1000 × 600mm
- Min cardboard size
- 50 × 50mm
- Speed
- 25–35pcs/min
- Positioning accuracy
- ±0.5mm
- Power
- 1kW
ASize range
| Parameter | Min | Max |
|---|---|---|
| Cardboard size | 50 × 50 mm | 1000 × 600 mm |
| Gap between holes | 55–430 mm | |
| Distance from board edge | 1–150 mm | |
BMaterial
| Magnet size | Round φ6–18 mm; square 10 × 10 to 20 × 20 mm |
| Magnet thickness | 1–5 mm |
| Cardboard thickness | 0.3–5 mm |
CPerformance
| Positioning accuracy | ±0.5 mm |
| Speed | 25–35 pcs/min |
DElectrical & footprint
| Air pressure | 0.6–0.8 MPa |
| Power supply | 220 V, 50–60 Hz |
| Power | 1 kW |
| Machine weight | 170 kg |
| Machine dimensions (L × W × H) | 1050 × 650 × 1550 mm |
1050
650
0.7 m² floor area, mm
Line position
Where the HF-600B sits in a line.
This machine
After
Ends the sequence: the piece leaves this machine finished for this stage.
FAQ
Questions about the HF-600B.
What sizes does the HF-600B handle?
For the HF-600B, max cardboard size: 1000 × 600 mm; min cardboard size: 50 × 50 mm.
How fast is the HF-600B?
The HF-600B runs at 25–35 pcs/min. Speed is counted in single pieces, not sets.
What materials can the HF-600B run?
On the HF-600B, magnet size: Round φ6–18 mm; square 10 × 10 to 20 × 20 mm; magnet thickness: 1–5 mm; cardboard thickness: 0.3–5 mm.
What power and air supply does the HF-600B need?
The HF-600B needs air pressure: 0.6–0.8 MPa; power supply: 220 V, 50–60 Hz; power: 1 kW.
How large and heavy is the HF-600B?
For the HF-600B, machine weight: 170 kg; machine dimensions (L × W × H): 1050 × 650 × 1550 mm.
Which machines work with the HF-600B?
It is fed by the HF-7090ZK Semi Automatic Drilling Machine. Which of these you need depends on the box structure and how much of the line is already in place.
