HF-450Automatic Rigid Box Forming Machine

Takes a glued, positioned box and finishes it: wraps the paper up the sides, folds the ears and turns the paper in. Box size is typed on the touch screen and the machine sets itself. Positioned by the supplier as an entry-level machine.

Max finished box size: 480 × 400 × 120mm
Min finished box size: 45 × 45 × 15mm
Production speed: 15–20pcs/min
Machine power: 2.5 kW / 220 V

Specifications

ASize range

Parameter	Min	Max
Paper turn-in depth	10–80 mm
Paper corner (ear) size	10–90 mm
Finished box size (L × W × H)	45 × 45 × 15 mm	480 × 400 × 120 mm

BMaterial

Cardboard thickness

0.8–4 mm

CPerformance

Production speed

15–20 pcs/min

DElectrical & footprint

Air supply	0.6–0.8 MPa
Machine power	2.5 kW / 220 V
Machine weight	1,000 kg
Machine dimensions (L × W × H)	1400 × 1100 × 2050 mm

Footprint · to scale

1400

1100

1.5 m² floor area, mm

Features

How the HF-450 is built.

01
Delta or Panasonic PLC with touch screen.
02
Delta servo motor and VFD.
03
Digital setting: enter the box size and the forming parameters are set automatically.
04
Light-curtain safety guard.
05
Built-in air-bubble pressing.
06
Custom size ranges on request.

Line position

Where the HF-450 sits in a line.

Before

HF-850AAutomatic Paper Gluing Machine

HF-500Automatic Rigid Box Corner Pasting Machine

HF-1050Automatic Visual Positioning Machine for Rigid Box and Hardcover

This machine

HF-450Rigid Box Making · 15–20 pcs/min

After

Ends the sequence: the piece leaves this machine finished for this stage.

FAQ

Questions about the HF-450.

What sizes does the HF-450 handle?

For the HF-450, max finished box size (L × W × H): 480 × 400 × 120 mm; min finished box size (L × W × H): 45 × 45 × 15 mm.

How fast is the HF-450?

The HF-450 runs at 15–20 pcs/min. Speed is counted in single pieces, not sets.

What materials can the HF-450 run?

On the HF-450, cardboard thickness: 0.8–4 mm.

What power and air supply does the HF-450 need?

The HF-450 needs air supply: 0.6–0.8 MPa; machine power: 2.5 kW / 220 V.

How large and heavy is the HF-450?

For the HF-450, machine weight: 1,000 kg; machine dimensions (L × W × H): 1400 × 1100 × 2050 mm.

Which machines work with the HF-450?

It is fed by the HF-850A Automatic Paper Gluing Machine, HF-500 Automatic Rigid Box Corner Pasting Machine, HF-1050 Automatic Visual Positioning Machine for Rigid Box and Hardcover. Which of these you need depends on the box structure and how much of the line is already in place.
